The mechanical components of the 6T30/40/45/50 are as follows:

  • A torque converter with an electronically controlled capacity clutch (ECCC)
  • Gear-type fluid pump assembly
  • 1??? and low and reverse clutch housing assembly
  • 4?? and 3? reverse clutch housing assembly
  • 2? clutch assembly
  • Low and reverse clutch (one way clutch) assembly
  • Control valve body assembly
  • Drive sprocket, driven sprocket and link assembly
  • Front differential carrier assembly
  • Input Carrier Assembly
  • Reaction Carrier Assembly
  • Output Carrier Assembly

The electrical components of the 6T30/40/45 are as follows:

  • Output speed sensor assembly
  • Input speed sensor assembly
  • Manual shift shaft with internal mode switch
  • Control solenoid valve assembly, which contains the following components:
    • Transmission control module (TCM)
    • 5 variable bleed line pressure control (PC) solenoids
    • Transmission fluid pressure (TFP) switch assembly
    • Torque converter clutch (TCC) pressure control solenoid
    • shift solenoid
    • Transmission fluid temperature sensor

For more information, refer to Electronic Component Description.
