Kia Soul: Rear combination light bulb replacement

Kia Soul: Rear combination light bulb replacement

Type A

Type A

Type B

Type B

(1) Tail light and side marker
(2) Rear turn signal light
(3) Back-up light
(4) Stop and tail light
(5) Tail light
(6) Stop and tail (LED)

1. Open the tailgate.

1. Open the tailgate.
2. Loosen the light assembly retaining screws with a philips head screwdriver.
3. Remove the rear combination light assembly from the body of the vehicle.

Tail light and side marker, Turn signal light and Stop and tail light

Tail light and side marker, Turn signal light and Stop and tail light

4. Remove the socket from the assembly by turning the socket counterclockwise until the tabs on the socket align with the slots on the assembly.
5. Remove the bulb from the socket by pressing it in and rotating it counterclockwise until the tabs on the bulb align with the slots in the socket.
6. Insert a new bulb by inserting it into the socket and rotating it until it locks into place.
7. Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly and turning the socket clockwise.
8. Reinstall the light assembly to the body of the vehicle.

Back-up light and Tail light

Back-up light and Tail light

Follow the steps 1 to 3 from the previous page.

4.Remove the socket from the assembly by turning the socket counterclockwise until the tabs on the socket align with the slots on the assembly.
5.Pull the bulb out of the socket.
6.Insert a new bulb into the socket.
7.Install the socket into the assembly by aligning the tabs on the socket with the slots on the assembly and turning the socket clockwise.
8.Reinstall the light assembly to the body of the vehicle.
