Turn the ignition switch OFF.
Disconnect the temperature control actuator connector.
Verify that the temperature control actuator operates to the cool position when connecting 12V to terminal 3 and grounding terminal 7.
Verify that the temperature control actuator operates to the warm position when connected in reverse.


3. Cool position
4. Sensor (+ 5V)
5. Feedback signal
6. Sensor ground
7. Warm position

Connect the temperature control actuator connector.
Turn the ignition switch ON.
Check the voltage between terminal 5 and 6.
Specification
Door Position
Voltage (V)
Error Detecting
Max. cooling
0.3±0.15
Low voltage : 0.1V or less
High voltage : 4.9V or more
Max. heating
4.7±0.15

It will feedback the current position of the actuator to controls.
If the measured voltage is not within specification, substitute with a known-good temperature control actuator and check for proper operation.
Replace the temperature control actuator if it is proved that there is a problem with it.
