Mazda 3 Service Manual: Back Up Light Switch Removal/Installation [G66 M R]

1. Remove the battery cover..

2. Disconnect the negative battery cable.

3. Remove the battery component. (ex: battery, battery tray and PCM component).

4. Remove the aerodynamic under cover No.2..

5. Drain the oil from the transaxle..

6. Disconnect the back-up light switch connector and remove the back-up light switch.


7. Install the back-up light switch (with a new gasket) to the transaxle case.

  • Tightening torque
  • 20—29 N·m {2.1—2.9 kgf·m, 15—21 ft·lbf}

8. Install the battery component. (ex: battery, battery tray and PCM component).

9. Install the battery cover..

10. Add the specified amount and type of oil..

11. Install the aerodynamic under cover No.2..
