Mazda 3 Service Manual: Front Center Speaker Inspection

Mazda 3 Service Manual: Front Center Speaker Inspection

1. Disconnect the negative battery cable..

2. Remove the following parts:

a. Upper column cover.

b. Instrument cluster.

c. Center panel.

d. Center cover.

e. Dashboard upper panel.

f. Front center speaker.

3. Verify the resistance between the front center speaker terminals.


  • If not within the specification, replace the front center speaker.


  • Resistance
  • 3.24—3.96 ohms
