Resistance Inspection

1. Remove the battery cover..

2. Disconnect the negative battery cable..

3. Disconnect the fuel injector connector.

4. Inspect the resistance between fuel injector terminals A and B.


  • Fuel injector resistance
  • 11.4—12.6 ohms [20 °C {68 °F}]

  • If not within the specification, replace the fuel injector..
