Mazda 3 Service Manual: Washer Tank Removal/Installation

Vehicles with the washer fluid-level sensor

1. Disconnect the negative battery cable..

2. Remove the front bumper..

3. Remove in the order indicated in the table.


1

Washer motor connector

2

Windshield washer hose

3

Rear washer hose (5HB)

4

Washer fluid-level sensor connector

5

Nut

6

Bolt

7

Hook

8

Washer tank


4. Install in the reverse order of removal.

Vehicles without the washer fluid-level sensor

1. Disconnect the negative battery cable..

2. Remove the front bumper..

3. Remove in the order indicated in the table.


1

Washer motor connector

2

Windshield washer hose

3

Rear washer hose (5HB)

4

Nut

5

Bolt

6

Hook

7

Washer tank


4. Install in the reverse order of removal.
