FWD

FWD : Exploded View

FWD : Exploded View

  1. Fuel filler cap
  2.  Grommet
  3.  Fuel filler tube
  4.  Cover
  5.  Clamp
  6.  Fuel filler hose
  7.  Clamp
  8.  Vent hose
  9.  Fuel tank protector
  10.  Fuel tank strap (LH)
  11.  Fuel tank strap (RH)
  12.  Fuel tank
  1.  To EVAP canister

: N·m (kg-m, in-lb)

FWD : Removal and Installation

REMOVAL

WARNING: Be sure to read “General Precautions” when working on the fuel system. Refer to FL-2, "General Precaution".

  1. Check the fuel level with the vehicle on a level surface. If the fuel gauge indicates more than the level as shown (1/2 full), drain the fuel from the fuel tank until the fuel gauge indicates a level at or below as shown (1/2 full).
  •  In case the fuel pump does not operate, use the following procedure.
  1.  Insert fuel tubing of less than 25mm (0.98in) diameter into the fuel filler tube through the fuel filler opening to drain fuel from the fuel filler tube.
  2.  Disconnect the fuel filler hose from the fuel filler tube.
  3.  Insert fuel tubing into the fuel tank through the fuel filler hose to drain fuel from the fuel tank.
  •  As a guide, the fuel level reaches or is less than the level on the fuel gauge as shown, when approximately 27.5(7-1/4 US gal, 6 Imp gal) of fuel is drained from a full fuel tank.

FWD : Removal and Installation

  1. Release the fuel pressure from the fuel lines. Refer to EC-144, "Work Procedure".
  2.  Disconnect negative battery terminal. Refer to PG-75, "Removal and Installation (Battery)".
  3.  Unscrew the fuel filler cap to release the pressure inside the fuel tank.
  4.  Remove second row seat (RH). Refer to SE-37, "Exploded View".
  5.  Turn the four retainers 90 degrees to disengage the clips and remove the fuel pump inspection hole cover.

    CAUTION: Cover the immeditate area surrounding the fuel pump inspection hole cover with plastic to avoid gasoline damage to carpet.

  6.  Disconnect harness connector (A) and quick connector (B).

FWD : Removal and Installation

: Front

Disconnect quick connector as follows:

  •  Hold the sides of connector, press tabs and pull out fuel feed tube.

FWD : Removal and Installation

(A) : Pull
(B) : Push in tabs

  • If quick connector sticks to tube of main fuel level sensor unit, push and pull quick connectors several times until they start to move. Then disconnect them by pulling.

CAUTION:

  • Quick connector (1) can be disconnected when the tabs (F) are depressed completely. Do not twist it more than necessary.

FWD : Removal and Installation

(B) : Connection (cross-section)
(D) : To under floor fuel line
(E) : To fuel tank
(G) : Disconnection

  • Do not use any tools to disconnected quick connector.
  • Keep resin tube (C) away from heat. Be especially careful when welding near the resin tube.
  • Prevent acid liquid such as battery electrolyte, etc. from getting on resin tube.
  • Do not bend or twist resin tube during installation and disconnection.
  • Do not remove the remaining retainer (2) on hard tube (or the equivalent) (A) except when resin tube or retainer is replaced.
  • When resin tube or hard tube (or the equivalent) is replaced, also replace retainer with new one.
  •  To keep the connecting portion clean and to avoid damage and foreign materials, cover them completely with plastic bags (A) or something similar.

FWD : Removal and Installation

  1. Remove center exhaust tube and muffler assembly. Refer to EX-5, "Exploded View".
  2.  Remove protector from fuel tank.
  3.  Remove vent hose (1) at rear side of fuel tank.
  4.  Disconnect EVAP tube (2) at rear side of fuel tank.
  •  Instruction for quick connector (A) of EVAP tube. Refer to FL- 5, "Quick Connector".
  1.  Remove fuel filler hose (3) at fuel filler tube side.

FWD : Removal and Installation

: Front

  1. Remove parking brake cable bolts and separate parking brake cable from suspension arm. Refer to PB-7, "Exploded View".
  2.  Remove rear suspension bars. Refer to RSU-22, "Exploded View".
  3. Support center of fuel tank (1) with suitable jack (A).

CAUTION: Securely support the fuel tank with a piece of wood (B).

Fuel filler hose

  1. Remove fuel tank bands.
  2.  Lower suitable jack carefully to remove fuel tank while holding it by hand.

    CAUTION: Fuel tank may be in an unstable condition because of the shape of fuel tank bottom. Be sure to secure fuel tank at all times.

  3.  If replacing the fuel tank, remove the fuel level sensor unit, fuel filter and fuel pump assembly to transfer to the new fuel tank. Remove and discard the O-ring. Refer to FL-6, "Removal and Installation".

INSTALLATION

Installation is in the reverse order of removal.

Fuel Filler Hose

  •  Insert fuel filler hose to the length below.

: 35 mm (1.38 in)

  • Be sure hose clamp is not placed on swelled area of fuel filler tube.
  •  Tighten the clamp hand with the top mark (A) until the mark is on the bolt head flange.

Awd

FWD : Inspection

INSPECTION AFTER INSTALLATION

Use the following procedure to check for fuel leaks.

  1.  Turn the ignition switch ON (without starting the engine). Then check the connections for fuel leaks by applying fuel pressure to the fuel piping.
  2.  Start engine, raise idle and verify there are no leaks at the fuel system connections.

AWD

AWD : Exploded View

  1. Fuel filler cap
  2. Grommet
  3. Fuel filler tube
  4.  Cover
  5. Clamp
  6. Fuel filler hose
  7.  Clamp
  8. Vent hose
  9. Fuel tank protector
  10.  Fuel tank strap (LH)
  11.  Fuel tank strap (RH)
  12.  Fuel tank
  1.  To EVAP canister

  : N·m (kg-m, in-lb)

AWD : Removal and Installation

REMOVAL

WARNING: Be sure to read “General Precautions” when working on the fuel system. Refer to FL-2, "General Precaution".

  1.  Check the fuel level with the vehicle on a level surface. If the fuel gauge indicates more than the level as shown (1/2 full), drain the fuel from the fuel tank until the fuel gauge indicates a level at or below as shown (1/2 full).
  •  In case the fuel pump does not operate, use the following procedure.
  1.  Insert fuel tubing of less than 25mm (0.98in) diameter into the fuel filler tube through the fuel filler opening to drain fuel from the fuel filler tube.
  2.  Disconnect the fuel filler hose from the fuel filler tube.
  3.  Insert fuel tubing into the fuel tank through the fuel filler hose to drain fuel from the fuel tank.

AWD : Removal and Installation

  • As a guide, the fuel level reaches or is less than the level on the fuel gauge as shown, when approximately 27.5(7-1/4 US gal, 6 Imp gal) of fuel is drained from a full fuel tank.
  1. Release the fuel pressure from the fuel lines. Refer to EC-144, "Work Procedure".
  2.  Disconnect negative battery terminal. Refer to PG-75, "Removal and Installation (Battery)".
  3.  Unscrew the fuel filler cap to release the pressure inside the fuel tank.
  4.  Remove second row seat (RH). Refer to SE-37, "Exploded View".
  5.  Turn the four retainers 90 degrees to disengage the clips and remove the fuel pump inspection hole cover..

    CAUTION: Cover the immeditate area surrounding the fuel pump inspection hole cover with plastic to avoid gasoline damage to carpet.

  6.  Remove center exhaust tube and muffler assembly. Refer to EX-5, "Exploded View".
  7.  Remove propeller shaft. Refer to DLN-99, "Removal and Installation".
  8.  Remove protector from fuel tank.
  9.  Remove vent hose (1) at rear side of fuel tank.
  10.  Disconnect EVAP tube (2) at rear side of fuel tank.
  •  Instruction for quick connector (A) of EVAP tube. Refer to FL- 5, "Quick Connector".
  1.  Remove fuel filler hose (3) at fuel filler tube side.

AWD : Removal and Installation

: Front

  1. Remove parking brake cable bolts and separate parking brake cable from suspension arm. Refer to PB-7, "Exploded View".
  2.  Remove rear suspension bars. Refer to RSU-22, "Exploded View".
  3.  Support center of fuel tank (1) with suitable jack (A).

CAUTION: Securely support the fuel tank with a piece of wood (B).

AWD : Removal and Installation

  1. Remove fuel tank bands.
  2.  Lower suitable jack carefully to remove fuel tank while holding it by hand.

    CAUTION: Fuel tank may be in an unstable condition, due to the shape of the fuel tank bottom. Be sure to secure tank at all times.

  3.  If replacing the fuel tank, remove the fuel level sensor unit, fuel filter and fuel pump assembly to transfer to the new fuel tank. Remove and discard the O-ring. Refer to FL-6, "Removal and Installation".

INSTALLATION

Installation is in the reverse order of removal.

Fuel Filler Hose

  •  Insert fuel filler hose to the length below.

: 35 mm (1.38 in)

  • Be sure hose clamp is not placed on swelled area of fuel filler tube.
  •  Tighten the clamp hand with the top mark (A) until the mark is on the bolt head flange.

Fuel Filler Hose

AWD : Inspection

INSPECTION AFTER INSTALLATION

Use the following procedure to check for fuel leaks.

  1.  Turn the ignition switch ON (without starting the engine). Then check the connections for fuel leaks by applying fuel pressure to the fuel piping.
  2.  Start engine, raise idle and verify there are no leaks at the fuel system connections.
EVAP canister
Exploded View EVAP control system pressure sensor O-ring EVAP canister EVAP canister vent control valve EVAP canister vent control valve hose EVAP vent line  EVAP canister ...
