Nissan Sentra Service Manual: Rear lh side power window does not operate

Nissan Sentra Service Manual: Rear lh side power window does not operate

When both power window main switch and rear power window switch lh are operated

When both power window main switch and rear power window switch lh are operated : diagnosis procedure

1.CHECK REAR POWER WINDOW SWITCH LH

Check rear power window switch LH.

Refer to PWC-40, "REAR POWER WINDOW SWITCH : Diagnosis Procedure".

Is the inspection result normal? YES >> GO TO 2.

NO >> Repair or replace the malfunctioning parts.

2.CHECK REAR POWER WINDOW MOTOR LH

Check rear power window motor LH.

Refer to PWC-46, "REAR LH : Diagnosis Procedure".

Is the inspection result normal? YES >> GO TO 3.

NO >> Repair or replace the malfunctioning parts.

3.REPLACE POWER WINDOW MAIN SWITCH

  • Replace power window main switch.
  • Confirm the operation after replacement.

Is the result normal? YES >> INSPECTION END

NO >> Check intermittent incident. Refer to GI-39, "Intermittent Incident".

When rear power window switch lh is operated

When rear power window switch lh is operated : diagnosis procedure

1.CHECK REAR POWER WINDOW SWITCH LH POWER SUPPLY AND GROUND CIRCUIT

Check rear power window switch LH power supply and ground circuit.

Refer to PWC-40, "REAR POWER WINDOW SWITCH : Diagnosis Procedure".

Is the inspection result normal? YES >> GO TO 2.

NO >> Repair or replace the malfunctioning parts.

2.CHECK REAR POWER WINDOW SWITCH LH

Check rear power window switch LH.

Refer to PWC-40, "REAR POWER WINDOW SWITCH : Diagnosis Procedure".

Is the inspection result normal? YES >> GO TO 3.

NO >> Repair or replace the malfunctioning parts.

3.REPLACE POWER WINDOW MAIN SWITCH

  • Replace power window main switch.
  • Confirm the operation after replacement.

Is the result normal? YES >> INSPECTION END

NO >> Check intermittent incident. Refer to GI-39, "Intermittent Incident".

When power window main switch is operated

WHEN POWER WINDOW MAIN SWITCH IS OPERATED : Diagnosis Procedure

1.CHECK REAR POWER WINDOW SWITCH LH

Check rear power window switch LH.

Refer to PWC-40, "REAR POWER WINDOW SWITCH : Diagnosis Procedure".

Is the inspection result normal? YES >> GO TO 2.

NO >> Repair or replace the malfunctioning parts.

2.REPLACE POWER WINDOW MAIN SWITCH

  • Replace power window main switch.
  • Confirm the operation after replacement.

Is the result normal? YES >> INSPECTION END

NO >> Check intermittent incident. Refer to GI-39, "Intermittent Incident".
