How to proceed with troubleshooting
1 Vehicle brought to workshop 2 Customer problem analysis 3 Problem symptom confirmation 4 Circuit inspection 5 Repair or replace 6 Confirmation test 7 End Customer problem analysis check ...

Circuit description
The side squib (rh) circuit consists of the airbag sensor assy center and front seat airbag assy (rh). It causes the srs to deploy when the srs deployment conditions are satisfied. Dtc b0110/43 is recorded when a short is detected in the side squib (rh) circuit. Wiring diagram ...

Inspection procedure
1 Check d squib circuit(airbag sensor assy center – horn button assy) Disconnect the negative (–) terminal cable from the battery, and wait at least for 90 seconds.  disconnect the connectors between the airbag sensor assy center and the horn button assy.  for the orange c ...
