With the engine at operating temperature and turned off, check the oil level on the dipstick.

Checking the engine oil

  1. Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
  2. Holding a rag under the end, pull the dipstick out.
  • 2.7 L 4-cylinder (1ar-fe) engine

Toyota Highlander. Checking the engine oil


  • 3.5 L v6 (2gr-fe) engine

Toyota Highlander. Checking the engine oil


  1. Wipe the dipstick clean.
  2. Reinsert the dipstick fully.
  3. Holding a rag under the end, pull the dipstick out and check the oil level.

Toyota Highlander. Checking the engine oil


  1. Low
  2. Normal
  3. Excessive
  1. Wipe the dipstick and reinsert it fully.

Adding engine oil

If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine.

  • 2.7 L 4-cylinder (1ar-fe) engine

Toyota Highlander. Adding engine oil


  • 3.5 L v6 (2gr-fe) engine

Toyota Highlander. Adding engine oil


Make sure to check the oil type and prepare the items needed before adding oil.

Engine oil selection
Oil quantity (low - full) 1.6 Qt. (1.5 L, 1.3 Imp. Qt.)
Items Clean funnel
  1. Remove the oil filler cap by turning it counterclockwise.
  2. Add engine oil slowly, checking the dipstick.
  3. Install the oil filler cap by turning it clockwise.
Engine compartment
2.7 L 4-cylinder (1ar-fe) engine Washer fluid tank   Fuse boxes Engine oil level dipstick   Engine oil filler cap   Engine coolant reservoir   Battery Bra ...
Engine oil consumption
A certain amount of engine oil will be consumed while driving.
