REPLACEMENT

HINT: COMPONENTS: SEE PAGE 30-4 Replace the RH side by the same procedures with the LH side.

1. REMOVE REAR WHEEL

2. SEPARATE REAR DISC BRAKE CALIPER ASSY LH

3. REMOVE REAR DISC (SEE PAGE 32-29 )

4. DISCONNECT SKID CONTROL SENSOR

(a) Disconnect the connector.

5. REMOVE REAR AXLE HUB & BEARING ASSY LH

6. SEPARATE STRUT ROD ASSY REAR

7. SEPARATE REAR SUSPENSION ARM ASSY NO.2 LH

SEPARATE REAR SUSPENSION ARM ASSY NO.2 LH


(a) Remove the bolt, nut and rear suspension arm No. 2 from the rear axle carrier.

HINT: While fixing the nut, turn and remove the bolt.

8. SEPARATE REAR SUSPENSION ARM ASSY NO.1 LH

 SEPARATE REAR SUSPENSION ARM ASSY NO.1 LH


(a) Remove the bolt, nut and rear suspension arm No. 1 from the rear axle carrier.

HINT: While fixing the nut, turn and remove the bolt.

9. REMOVE REAR AXLE CARRIER SUB-ASSY LH

REMOVE REAR AXLE CARRIER SUB-ASSY LH


(a) Remove the 2 bolts, nuts and rear axle carrier from the shock absorber

10. INSTALL REAR AXLE CARRIER SUB-ASSY LH

INSTALL REAR AXLE CARRIER SUB-ASSY LH


(a) Install the rear axle carrier with the 2 bolts and nuts.

Torque: 180 NVm (1,840 kgfVcm, 133 ftVlbf)

HINT: Insert the bolt from the rear side of the vehicle and install the nut.

11. TEMPORARILY TIGHTEN REAR SUSPENSION ARM ASSY NO.1 LH

TEMPORARILY TIGHTEN REAR SUSPENSION ARM ASSY


(a) Install the rear suspension arm No. 1 to the rear axle carrier with the bolt and nut, temporarily tighten the bolt.

HINT: Insert the bolt from the front side of the vehicle and while fixing the nut, turn and install the bolt.

12. TEMPORARILY TIGHTEN REAR SUSPENSION ARM ASSY NO.2 LH

 TEMPORARILY TIGHTEN REAR SUSPENSION ARM ASSY


(a) Install the rear suspension arm No. 2 to the rear axle carrier with the bolt and nut, temporarily tighten the bolt.

HINT: Insert the bolt from the rear side of the vehicle and while fixing the nut, turn and install the bolt.

13. TEMPORARILY TIGHTEN STRUT ROD ASSY REAR (SEE PAGE 27-13 )

14. INSTALL REAR AXLE HUB & BEARING ASSY LH (SEE PAGE 30-53 )

15. INSPECT BEARING BACKLASH (SEE PAGE 30-3 )

16. INSPECT AXLE HUB DEVIATION (SEE PAGE 30-3 )

17. CONNECT SKID CONTROL SENSOR

(a) Connect the connector.

NOTICE: Do not twist the sensor wire when connecting it.

18. INSTALL REAR DISC (SEE PAGE 32-29 )

19. INSTALL REAR DISC BRAKE CALIPER ASSY LH (SEE PAGE 30-53 )

20. INSTALL REAR WHEEL

Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)

21. STABILIZE SUSPENSION (SEE PAGE 27-27 )

22. FULLY TIGHTEN REAR SUSPENSION ARM ASSY NO.1 LH (SEE PAGE 27-16 )

23. FULLY TIGHTEN REAR SUSPENSION ARM ASSY NO.2 LH (SEE PAGE 27-23 )

24. FULLY TIGHTEN STRUT ROD ASSY REAR (SEE PAGE 27-13 )

25. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (SEE PAGE 27-5 )
