Toyota Highlander Service Manual: Rear axle hub bearing ASSY LH (FF)

Toyota Highlander Service Manual: Rear axle hub & bearing ASSY LH (FF)

REPLACEMENT

HINT: COMPONENTS: SEE PAGE 30-4 Replace the RH side by the same procedures with LH side.

1. REMOVE REAR WHEEL

2. SEPARATE RR DISC BRAKE CALIPER ASSY RH

SEPARATE RR DISC BRAKE CALIPER ASSY RH


(a) Remove the bolt and separate the flexible hose.

SEPARATE RR DISC BRAKE CALIPER ASSY RH


(b) Remove the 2 bolts and brake caliper.

(c) Support the brake caliper securely.

3. REMOVE REAR DISC (SEE PAGE 32-29 )

4. SEPARATE SKID CONTROL SENSOR WIRE

(a) Disconnect the connector.

5. REMOVE REAR AXLE HUB & BEARING ASSY LH

REMOVE REAR AXLE HUB & BEARING ASSY LH


(a) Remove the 4 bolts and axle hub.

6. INSTALL REAR AXLE HUB & BEARING ASSY LH

INSTALL REAR AXLE HUB & BEARING ASSY LH


(a) Install the axle hub with the 4 bolts.

Torque: 80 NVm (816 kgfVcm, 59 ftVlbf)

7. INSTALL SKID CONTROL SENSOR WIRE

(a) Connect the connector.

8. INSPECT BEARING BACKLASH

INSPECT BEARING BACKLASH


(a) Set a dial indicator near the center of the axle hub and check the backlash in the bearing shaft direction.

Maximum: 0 mm (0 in.)

If the backlash exceeds the maximum, replace the axle hub assembly.

9. INSPECT AXLE HUB DEVIATION

INSPECT AXLE HUB DEVIATION


(a) Using a dial indicator, check the deviation at the surface of the axle hub outside the hub bolt.

Maximum: 0.08 mm (0.0031 in.)

If the backlash exceeds the maximum, replace the axle hub assembly.

10. INSTALL REAR DISC (SEE PAGE 32-29 )

11. INSTALL RR DISC BRAKE CALIPER ASSY RH

INSTALL RR DISC BRAKE CALIPER ASSY RH


(a) Install the brake caliper with the 2 bolts.

Torque: 78 NVm (800 kgfVcm, 58 ftVlbf)

INSTALL RR DISC BRAKE CALIPER ASSY RH


(b) Install the flexible hose with the bolt.

Torque: 19 NVm (194 kgfVcm, 14 ftVlbf)

12. INSTALL REAR WHEEL Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)

13. INSPECT REAR WHEEL ALIGNMENT (SEE PAGE 27-5 )

14. CHECK ABS SPEED SENSOR SIGNAL (SEE PAGE 05-765 )
