HINT:

  • The installation procedures are the removal procedures in reverse order. However, only installation procedures requiring additional information are included.
  • Use the same procedures for the RH side and LH side.
  • The procedures listed below are for the RH side.
  • A bolt without a torque specification is shown in the standard bolt chart (see page 03-2 ).

1. Manual seat type: REMOVE FRONT SEAT INNER BELT ASSY RH

CAUTION:

  • Removal of the seat belt pretensioner must be started at least 90 seconds after the ignition switch is turned OFF and the negative (-) terminal cable is disconnected from the battery.
  • Carefully read the notices for the "pretensioner" in the SRS airbag system section and the front seat outer belt section (see page 60-1 ).

(a) Remove the front seat RH (see page 72-1 1).

(b) Remove the front seat cushion shield inner RH (see page 72-1 1).

(c) Remove the front seat inner belt RH.

  1.  Disconnect the connector and clamp.
  2.  Remove the nut and belt.

REMOVE FRONT SEAT INNER BELT ASSY RH


(d) Install the front seat inner belt RH.

  1.  Install the belt with the nut.

    Torque: 42 NVm (428 kgfVcm, 31 ftVlbf)

NOTICE: Do not allow the anchor part of the front belt and the protruding part of the floor panel to overlap.

(e) Connect the clamp and connector.

(f) Connect the battery's negative battery terminal..

(g) Initialize the occupant classification sensor (see page 72-1 1 or 72-19 )..

(h) Check the SRS warning lamp (see page 60-1 ).

2. Power seat type: REMOVE FRONT SEAT INNER BELT ASSY RH

CAUTION:

  • Removal of the seat belt pretensioner must be started at least 90 seconds after the ignition switch is turned OFF and the negative (-) terminal cable is disconnected from the battery.
  • Carefully read the notices for the "pretensioner" in the SRS airbag system section and the front seat outer belt section (see page 60-1 ).

(a) Remove the front seat assy RH (see page 72-1 1).

(b) Remove the power seat switch knobs (see page 72-1 1).

(c) Disconnect the connector and clamp.

(d) Remove the nut and belt.

REMOVE FRONT SEAT INNER BELT ASSY RH


(e) Install the belt with the nut.

Torque: 42 NVm (428 kgfVcm, 31 ftVlbf)

NOTICE: Do not allow the anchor part of the front belt and the protruding part of the floor panel to overlap.

(f) Connect the clamp and connector.

(g) Connect the battery's negative battery terminal.

(h) Initialize the occupant classification sensor (see page 72-1 1 or 72-19 ).

(i) Check the SRS warning lamp (see page 60-1 ).

3. REMOVE FRONT SEAT OUTER BELT ASSY RH

CAUTION:

  • Removal of the seat belt pretensioner must be started at least 90 seconds after the ignition switch is turned OFF and the negative (-) terminal cable is disconnected from the battery.
  • Carefully read the notices for the "pretensioner" in the SRS airbag system section and the front seat outer belt section (see page 60-1 ).

(a) Remove the front door scuff plate RH (see page 76-21 ).

(b) Remove the rear door scuff plate RH (see page 76-21 ).

(c) Remove the front door opening trim weatherstrip (see page 76-21 ).

(d) Remove the rear door opening trim weatherstrip (see page 76-21 ).

(e) Remove the center pillar garnish lower RH (see page 76-21 ).

REMOVE FRONT SEAT OUTER BELT ASSY RH


(f) Remove the front seat outer belt assy RH.

  1.  Using a screwdriver, disengage the 4 claws and remove the shoulder belt anchor cover.

    HINT: Tape the screwdriver tip before use.

  2.  Remove the bolt and shoulder anchor.

REMOVE FRONT SEAT OUTER BELT ASSY RH


  1. Using a screwdriver, disengage the 2 claws and remove the floor belt anchor cover.

HINT: Tape the screwdriver tip before use.

REMOVE FRONT SEAT OUTER BELT ASSY RH


  1. Disconnect the pretensioner connector, as shown in the illustration.
  2.  Remove the 2 bolts and outer belt.

REMOVE FRONT SEAT OUTER BELT ASSY RH


(g) Install the front seat outer belt assy RH.

  1.  Check the amount of inclination required to lock the retractor.
  • When the inclination of the retractor is 15 or less, check that the belt can be pulled from the retractor. When the inclination of the retractor is over 45 , check that the belt locks.

NOTICE: Do not disassemble the retractor.

If operation is not as specified, replace the outer belt assy.

  1.  Install the front seat outer belt assy RH.

Torque: 7.5 NVm (77 kgfVcm, 66 in.Vlbf) for upper bolt 42 NVm (428 kgfVcm, 31 ftVlbf) for lower bolt

REMOVE FRONT SEAT OUTER BELT ASSY RH


  1. Connect the pretensioner connector, as shown in the illustration.
  2.  Install the shoulder belt anchor to the shoulder belt anchor adjuster with the bolt.

Torque: 42 NVm (428 kgfVcm, 31 ftVlbf)

(h) Install the center pillar garnish lower.

(i) Install the floor anchor to the front seat with the bolt.

Torque: 42 NVm (428 kgfVcm, 31 ftVlbf)

(j) Install the front door scuff plate.

(k) Install the rear door scuff plate.

(l) Install the front door opening trim weatherstrip.

(m) Install the rear door opening trim weatherstrip.

(n) Connect the battery's negative battery terminal.

(o) Initialize the occupant classification sensor (see page 72-1 1 or 72-19 ).

(p) Check the SRS warning lamp (see page 60-1 ).

Disposal
HINT: When scrapping vehicles equipped with a seat belt pretensioner or disposing of a front seat outer belt (with seat belt pretensioner), always first activate the seat belt pretensioner in ac ...
