Starter relay
On-vehicle inspection Disconnect cable from negative battery terminal Caution: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. Remove starter relay Remove the starter relay fr ...

Installation
Install crankshaft position sensor Notice: Make sure that the o-ring is not cracked or jammed when installing it. Apply a light coat of engine oil to the o-ring of the sensor. Install the sensor with the bolt. Torque: 9.0 N*m (90 kgf*cm, 80 in.*Lbf) Install the wire ha ...

Reassembly
Hint: Use high-temperature grease to lubricate the bearings, gears, return spring and steel ball when assembling the starter. Install planetary gear Apply grease to the planetary gears and pin parts of the planetary shaft. Install the 3 planetary gears. Install starter arm ...
