Distance display

Sensors that detect an obstacle will illuminate continuously or blink.

Toyota Sienna. Distance display


*1: The images may differ from that shown in the illustrations. *2: Multi-information display *3: Audio system screen

Buzzer operation and distance to an obstacle

A buzzer sounds when the sensors are operating.

  • The buzzer sounds faster as the vehicle approaches an obstacle.

    When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously.

  • Front and rear corner sensors: Approximately 0.8 ft. (25 cm)
  • Rear center sensors: Approximately 1.1 ft. (35 cm)
  • When 2 or more obstacles are detected simultaneously, the buzzer system responds to the nearest obstacle. If one or both come within the above distances, the beep will repeat a long tone, followed by fast beeps.
Display
When the sensors detect an obstacle, the following displays inform the driver of the position and distance to the obstacle. Multi-information display Front corner sensor operation Rear cor ...
