1. DATA LIST

HINT: By the DATA LIST displayed by the intelligent tester, you can read the value of the switch, sensor, actuator and so on without removing any part. Reading the DATA LIST as the first step in troubleshooting is one of the methods to shorten the labor time.

  1.  Connect the intelligent tester to DLC3.
  2.  Turn the ignition switch ON.
  3.  According to the display on the tester, read the "DATA LIST".

BODY NO.1:

BODY NO.1

BODY NO.1

BACK DOOR:

BACK DOOR

2. ACTIVE TEST

HINT: Performing the ACTIVE TEST using the intelligent tester allows the relay, VSV, actuator and so on to operate without removing any part. Performing the ACTIVE TEST as the first step of troubleshooting is one of the methods to shorten the labor time. The DATA LIST can be displayed during the ACTIVE TEST.

  1.  Connect the intelligent tester to DLC3.
  2.  Turn the ignition switch ON.
  3.  According to the display on the tester, perform the "ACTIVE TEST".
