Components

COMPONENTS

ILLUSTRATION Removal

Removal

REMOVAL

PROCEDURE

1. REMOVE INSTRUMENT PANEL LOWER CENTER FINISH PANEL

(See page2. REMOVE NO. 1 POWER OUTLET SOCKET ASSEMBLY)

2. REMOVE NO. 1 POWER OUTLET SOCKET ASSEMBLY

(a) Using a screwdriver with its tip wrapped in protective tape, disengage the 2 claws to remove the No. 1 power outlet socket assembly as shown in the illustration.

Text in Illustration

*a

Protective Tape

3. REMOVE NO. 1 POWER OUTLET SOCKET COVER

(a) Disengage the 2 claws to remove the No. 1 power outlet socket cover.

Installation

INSTALLATION

PROCEDURE

1. INSTALL NO. 1 POWER OUTLET SOCKET COVER

(a) Engage the 2 claws to install the No. 1 power outlet socket cover.

2. INSTALL NO. 1 POWER OUTLET SOCKET ASSEMBLY

(a) Engage the 2 claws to install the No. 1 power outlet socket assembly as shown in the illustration.

3. INSTALL INSTRUMENT PANEL LOWER CENTER FINISH PANEL

(See pagePower Outlet Socket(for Rear Side))
